LOOKIT 4 Port FXO VoIP System 200 IP User Hotel IPPBX Gateway with High Capacity Voice Connectivity
LOOKIT 4 Port FXO VoIP System 200 IP User Hotel IPPBX Gateway with High Capacity Voice Connectivity - Image 2
LOOKIT 4 Port FXO VoIP System 200 IP User Hotel IPPBX Gateway with High Capacity Voice Connectivity - Image 3
LOOKIT 4 Port FXO VoIP System 200 IP User Hotel IPPBX Gateway with High Capacity Voice Connectivity

$155.0

Why Choose This Gateway?

  • ✅ Hybrid Connectivity: 4 FXO ports connect to traditional phone lines while routing calls over IP to cut costs.
  • ✅ Hotel-Optimized: Purpose-built features for front desk efficiency and guest satisfaction.
  • ✅ Scalable & Secure: Grow with your property; SIP encryption and firewall support included.
  • ✅ Easy Deployment: Plug-and-play setup with remote management for IT teams.
Categories: /SKU: IPB10050087198/
  • 4 FXO Ports: Connect to analog PSTN lines for reliable fallback and hybrid telephony.
  • Supports up to 200 IP Users: Ideal for medium to large hotels, resorts, or guesthouses.
  • Integrated IPPBX Functionality: Built-in PBX eliminates the need for separate hardware.
  • Hotel-Specific Features: Wake-up calls, room billing integration, check-in/check-out call control.
  • VoIP Protocols: SIP-compliant for seamless integration with existing VoIP infrastructure.
  • Web-Based Management: Easy remote configuration and monitoring.
  • Failover & Redundancy: Automatic PSTN fallback ensures uninterrupted service.
Specification
Model
LTPBX140E-S4
LTPBX140E-S8
LTPBX140E-S16
LTPBX140E-S32
LTPBX1800E-S4
Network Interface
1*WAN+3*LAN，4*GE（RJ45）
User Interface
4FXS
8FXS
16FXS
32FXS
64FXS
IP user
200
Console port
1*Console port，RJ45，115200bps
USB
1 USB2.0，support FullSpeed
Power supply
100VAC～240VAC；50/60Hz
Enclosure
1U，matel material
Power
15W
20W
25W
45W
60W
Size/mm
230×140×33
340×210×43.5
 440×210×43.5
440×224.5×44
448*300*44.5
Voice protocol
IMS/NGN SIP, H.248
SIP v2.0, RFC3261, SDP, RTP(RFC2833)
RFC3262, 3263, 3264, 3265, 3515, 2976, 3311
RTP/RTCP, RFC2198, 1889, RFC4028 Session Timer
RFC3266 IPv6 in SDP, RFC2806 TEL URI, RFC3581, NAT, rport
Voice processing
Codec: G.711A, G.711U, G.729, G.723.1, G.722
Echo cancellation: G.168, tail length 64 ms
Support Voice Activity Detection(VAD)
Support DOTSCP/TOS tags
Digitmap
Voice service
Support basic call: caller ID, call forwarding, three-way call, hot line;
Implementation with IPPBX/IMS: call number display limit, unconditional call forward, busy call forward, no reply call forward,
find malicious call, call out limit, do not disturb, shrink dialing, alarm clock, busy callback, call waiting, call holding, etc.
QoS
Support speed limit based on VLAN, IP address segment, port, protocol
Support 802.1p and DOTSCP marks on traffic
Support to set traffic priority and secure bandwidth for critical services
Fax
Supports T.30, T.38 fax
Network management
Support local Web, SNMP, TR069, SYSLOG
